Expansion Shell

expansion shell 2

This is an expansion shell anchor used to secure fixtures in concrete by expanding to grip the surrounding material.

The Benefits:

Strong mechanical grip in concrete due to expansion action
Reliable load transfer for fixtures and connections
Quick and easy installation on site
Suitable for a range of fixing applications in concrete

Expansion shells are used for fixing single-sided shuttering or similar structures in rock, concrete or comparable load-bearing ground. When installing expansion shells, please consult the separate installation instructions available on demand.

Article No.	Bar Ø [mm]	Borehole Ø [mm]	Weight [kg/St.]
15 F 2128	15	32 – 34	0.20
15 F 2184	15	35 – 37	0.39
15 F 2190	15	35 – 37	0.42
20 F 2136	20	43 – 48	0.48
26 E 2137	26.5	51 – 53	0.60

Safety Instructions

Appropriate use of form ties and accessories is necessary to prevent accidents and failure. All products are intented to be used by qualified and experienced workmen. It is the user's responsibility to continually inspect working hardware for wear and to discard worn parts. Improper use of the DYWIDAG Form Ties can expose workers to extreme danger that may result in severe injury or death.
