contecSEAL 167 JGS

The contecSEAL 167 JGS joint sheet is specifically designed for sealing construction joints in storage and filling facilities of biogas and JGS plants. For construction joints in wall/wall, base/base, base/wall, and wall/ceiling applications, contecSEAL 167 JGS ensures a secure and durable seal against pressurized water and other common media used in biogas and JGS plants, up to a filling height of 20 meters and a joint expansion of up to 0.2 mm. Its range of applications extends from containers for manure or slurry to concrete surfaces and facilities for storing and filling media that require water protection.

Extensive testing and the general technical approval from the DIBt (Z-74.101-203) confirm the safe use of contecSEAL 167 JGS joint sheets in storage and filling facilities of biogas and JGS plants. contecSEAL 167 JGS can also be combined with many other versions of RECOSTAL® shuttering elements.

The Benefits:

• All the advantages of our well-known systems, technologically combined in one product

• DIBt approved (general technical approval Z-74.101-203)

• Galvanized steel sheet with double-sided pressure-sensitive and elastic special coating and granulate

• No rigid coating – deflections can be made directly

• Extremely high adhesive bond to concrete

• No protective film to be removed from the joint sheet

• Pre-applied contaflexaktiv active joint strip for secure joint formation

• Joints are easily secured with the corresponding joint clamps

• Tested up to 5 bar / approved up to 2 bar against water and all common media in biogas and JGS plants

• Minimum embedding depth of only 35 mm

• Overlap of joints only 50 mm
